SV400 Two-Component Injectable Epoxy Chemical Anchor Adhesive for Concrete

Short Description:

SV400 is a two-component injectable epoxy anchoring adhesive for threaded rods and rebar in cracked and uncracked concrete. It is thixotropic, shrinkage-free, suitable for damp concrete, and cures to 95 N/mm² compressive strength with a service temperature of -40 °C to +50 °C. Supplied in 400 ml and 600 ml cartridges, 20 per carton.

SV400 is formulated for structural post-installed connections: anchoring threaded rods and rebar into walls, slabs, columns and foundations, connecting structural steel, and strengthening concrete members in renovation and retrofit work. The epoxy system is solvent-free, low in emissions, and cures without shrinkage, so the bond develops full contact with the drilled hole wall even in damp concrete. Because it is injectable and thixotropic, it fills the hole from the bottom up without voids and does not run out of overhead or horizontal holes.

package: 400 ml and 600 ml coaxial cartridge, 20 pcs per carton

OEM / ODM : Private label, custom cartridge print and carton from 50 cartons

Send email to us

Product Detail

Product Tags

Product Description

SV400 is a two-component injectable epoxy anchoring adhesive for threaded rods and rebar in cracked and uncracked concrete.

FEATURES

1. Long open Time

2. Can be used in damp concrete

3. High load capacity

4. Suitable for contact with drinking water

5. Good adhesion to substrate

6. Shrinkage-free hardening

7. Low emissions

8. Low wastage

PACKAGING

Cartridge	Carton	Mixed volume
400 ml coaxial	20 pcs per carton	400 ml nominal
600 ml coaxial	20 pcs per carton	600 ml nominal

BASIC USES

1. Structural connections with post-installed rebar (e.g. extension/connection to walls, slabs, stairs, columns, foundations, etc.)

2. Structural renovation of buildings, bridges and other civil structures, retrofitting and re-strengthening of concrete members possible

3. Anchoring structural steel connections (e.g. steel columns, beams, etc.)

4. Fastenings requiring seismic qualification

5. Fastening in natural stone and wood, including GLT and CLT made by spruce, pine or fir.

TYPICAL PROPERTIES

These values are not intended for use in preparing specifications

Item		Standard	Result
Compressive strength		ASTM D 695	~95 N/mm2 (7 days, +20 °C)
Tensile strength in flexure		ASTM D 790	~45 N/mm2 (7 days, +20 °C)
Tensile strength		>ASTM D 638	~23 N/mm2 (7 days, +20 °C)
Service temperature	Long term	-40 °C min. / +50 °C max.
Service temperature	Short term (1–2 hours)	+70 °C

STORAGE AND SHELF LIFE

Should be stored at or below 27℃ in original unopened containers. It has a shelf life of 12 months from the date of manufacture.
